Our company specialized in aluminum coil /sheet/foil product
Stucco Embossed Aluminum Sheet
Thickness:0.06-3.0 mm
Width:100-1600 mm
Length:Less than 6000mm or customized
Weight:0.5-7.0 tons per pallet or customized
Temper:HO-H24
Surface treatment:Diamond embossed sheet /Texture aluminum sheet/Orange peel aluminum sheet
Painting type:PVDF (PPG brand) and PE(polyester)
Color Coating thickness:Topside of coil :25um (PVDF), 16-25um (PE) Backside of coil:8-10um(PE)
Color code:Solid color as per RAL Code
specification or package can be produced as your request.
INQUIRYThe Stucco Embossed Aluminum Sheet is our professional product, we are experienced to produce and supply this product. It can be used for antisepsis and heat preservation project, indoor and outdoor decoration, inner bag of refrigerator and deep freezer, construction of top-grade structure. With craft paper covering, it will be better for antisepsis, and can be used for antisepsis project construction of oil industry, electric power industry and chemical industry and top-grade structure.
| Product
Name |
Alloys Number | Temper | Thickness
（mm） |
Width
（mm） |
Length
（mm） |
Application |
| Stucco
Embossed Aluminum sheet
|
1100, 1050, 1060, 3003, 3004, 3005, 3104, 3105, 5005, 5052, 5754
8011 |
O,H12,H14,H16H18,H19,H22,H24,H26,H28,H32,H34H36,H38, H42 H44 | 0.06-3.0 | 100-1600 | 60-6000 | aluminium-plastic panel, aluminum honeycomb, roof corrugated board,fire veneer, aluminum ceiling, window-shades, roller shutter door, garage door, awning, overboard gutter), electric products (computer case, electrical panel), light-fixture, furniture, solar reflector, air duct, etc. |
Product Properties:
a. Light weight, and printable surface;
b. Outstanding color&gloss retention;
c. Superior impact&peeling strength;
d. Excellent surface flatness&smoothness
e. Various colors&easy to maintain
Performance：
The aluminum sheet is coated with PE/PVDF. Polyester coating formed by multiple baking and coating on the surface of aluminum plate can generate a fast and continuous solid film that acts as a kind of protection and decoration. This coating is UV resistant.
Polyester /PVDF resin contains high polymer with ester bond as the main chain and alkyd resin, which can protect objects from UV rays, wind, rain, frost, snow, ice and freezing when exposed to air, and cannot be influenced by temperature difference, freeze-thaw cycle, corrosive gas, or micro-organism. It is very suitable for making interior decorations and billboards.
Packing & Transportation Details:
1) Interleave paper between each sheet. (Optional for Cold Rolled Sheet).
2) Plate/coil is placed to the iron or wooden pallet, wrapped by water-proof craft paper and fixed by iron belt.
3) Port: Qingdao port or other main ports in China
4) Container: 20ft GP:5898mm (Length)x2352mm (Width)x2393mm (Height), loading 18~25 tons.
40ft GP:12032mm (Length)x2352mm (Width)x2393mm (Height), loading 20~28 tons.
